ELECTRONIC CENTRIFUGAL SWITCH

UNIVERSAL - FOR ANY SINGLE PHASE MOTOR

The smart replacement for any centrifugal switch used on any motor type, voltage, power, RPM and frequency.

ADVANCED FEATURES

DMS05U: works for ANY motor up to 5HP (4KW) - A solution for those who requiere more power.
DMS03U: works for ANY motor up to 3HP (2.4KW) - Lower cost for most of the market.

Every startup time is mathematically calculated as a function of the motor type, voltage and loading condition.



On high cycling condition (ON/OFF/ON) the motor’s coasting speed is measured avoiding any unnecessary startup or reduce it.



Problems associated with RPM tolerance, mechanic and electrical fatigue, vibration, humidity, dust, etc. Are eliminated avoiding erratic motor startups.



If there is a motor-locked condition during startup for more than 0.5s. The start circuit opens avoiding motor overheats or burn out.



If there is a motor-locked condition during normal operation. It will not be restarted unless the operator turns off the motor, find and fix the problem and turn it on again. Avoiding motor overheats or burn out that will otherwise occur due to a mechanical centrifugal switch trying to restart the motor.

© Copyrigth 2016 - All rights reserved - ISOVOLT ® All rights reserved

Products

DIGITAL MOTOR STARTER - UNIVERSAL ELECTRONIC CENTRIFUGAL SWITCH FOR SINGLE PHASE MOTORS

NAME DIGITAL MOTOR STARTER 3HP - 5HP
MODEL DMS03U - DMS05U
DESCRIPTION Universal Digital Motor Starter for Single Phase Motors up to 3HP-5HP 110/240VAC 50/60Hz
DATASHEET

1-PHASE MOTOR EXAMPLE CONNECTIONS


© Copyrigth 2016 - All rights reserved - ISOVOLT ® All rights reserved

Distributors

We invite you to join our distribution Network.


  CANADA
Acme Electric (Port Hope) Ltd
Port Hope, Ontario
Tel: 905-885-2469
www.acmeelectricltd.com
USA
USA EURTON ELECTRIC Co
Santa Fe Springs, CA 90670
Tel: 800-423-4789
www.eurtonelectric.com

AUSTRALIA
CEG Group pty Ltd
BRISBANE, Queensland
Tel: 07 - 3277 0377
www.ceg.co

  FIJI ISLANDS
Murrys Electrical Supplies
Samabula, Fiji Islands
Tel: +679 3386517
http://www.murryselect.com/
NEW ZEALAND
CEG Group pty Ltd
PALMERSTON NORTH
Tel: 06 - 357 8940
www.ceg.co
SINGAPORE
GEOMAN ELECTRICAL & CO
Singapore 208787
Tel: +65 64577159
www.geoman-tcy.com

      VENEZUELA
    FRANCAR
Av. Ppal Mariperez, Caracas
Tel: 0212-7936129
  Inversiones Fiorano
Carrera 18, Barquisimeto
Tel: 0251-2678039
  MIVALCA
Urb. Michelena, Valencia
Tel: 0241-5145237

    SUSERVEN
Av. Michelena, Valencia
Tel: 0241-8389784
  Alambre Multielectrico Maracay
Calle Mariño Sur, Maracay
Tel: 0243-2460694
  SUMIVEN S.A
Maracaibo, Zulia
Tel: 0261-7970430





© Copyrigth 2016 - All rights reserved - ISOVOLT ® All rights reserved

Applications

DMS Module Application Notes



3-PHASE MOTORS RUNNING ON 1-PHASE 208-220VAC SUPPLY

To energize pumps, compressors, motor-tools or any equipment based on 3-phase motors on electric facilities with only
1-phase 208-220VAC mains supply available, has been the main goal of different techniques and connections that were developed for this kind of operation.



  Download Application Notes:



1-PHASE MOTORS - START CAPACITOR VALUE

During the development of the DMS module, a lot of motors startups had been measured and analyzed in order to find the mathematical model to be used in the module software. Two issues not well known came up.



  Download Application Notes:
